2009 Fisher+Rueckle FANNINGMASTER 515 Veneer splitting machine

Veneer splitting machine FANNINGMASTER 515 for sale!

Roller conveyor INCLUDED

Veneer specifications

Veneer strip width (cross grain) 45 - 515 mm

Veneer strip length (grain direction) 400 - 4000 mm

Veneer strip thickness (depending on quality of veneer) 0,3 - 1,5 mm

Veneer package height 10 - 40 mm

Machine capacity

Throughput speed approx. 30 m/min.

Machine specifications

Electric energy 1,2 kW

Compressed air 6 bar

Power consumption

Compressed air consumption 5 NL/min.

Dimensions / weight

Measurements

Length 2360 mm

Width 1570 mm

Height 1750 mm

Net weight, approx. 1150 kg

Working table height 900 mm
