HASBORG Sprinkling device

Sprinkling device for different type of drops on the top of slab for confectionery products

The main components of the sprinkler conveyor assembly are: (see attachment)

1. Sprinkler basket with spreader;
2. Pressure roller;
3. Intermediate conveyor;
4. Main frame with lifting system;
5. Supplementary basket;
6. Rising conveyor;
7. Electrical box;
8. Upper cross conveyor

Dimensions (see attachment)

Working principle (see attachment)

Technical data

Supply voltage 400V

Operating frequency 50Hz

Control system voltage 24V DC

Length 3251 mm

Length of main transporter 1407 mm

Width 3065 mm

Height 2575

Working width of main conveyor 1150 mm

Power 3kW

Max. current consumption 7,5 A

Speed of the sprinkling basket 92 l

Required compressed air pressure 6-10 bars

Compressed air consumption 700 l/min

Max. height of sprinkled products 50-150 mm

Height of the sprinkling conveyor from the ground 1050-1150 mm

Max. liquid pressure in the hopper 2 bars
